Ekinex - KNX switch - basic version - FF serie - EK-E32-TP - NO LED)

The 4-fold pushbutton of Ekinex® FF series commands loads on/off switching, controls the dimming of lighting devices, controls motor drives for shutters or executes any other programmable command and control function. The device integrates a KNX bus communication module and is intended for mounting onto a wall mounting box; it is supplied by a SELV voltage directly from the KNX bus and does not require any auxiliary power supply.

Frame and buttons covers sold separately:

- Ekinex - 1 gang frame

- Ekinex - kit 4 buttons

JUNG-F40-universal push-button module 2-gang-42921 ST

4-gang control panel-42921 ST replaces 4192 TSM, key frames and covers remain the same.

for cover kit 2-gang, ref.-no.: .. 402 TSA ..
for cover 2-gang with symbols, ref.-no.: .. 402 TSAP ..
can be extended by means of a push-button extension module, ref.-no.: 409.. TSEM
Adapter frames are included in delivery:
ref.-no. LS 4 AR for LS range (pre-mounted) and ref.-no. CD 4 AR for CD range.
AS / A ranges without adapter frame.
Only with ETS 5.7.7 or later versions or ETS6.0.6 or later versions the full functionality will be available.
ETS product family: Push-button
Product type: 2-gang push-button
1 blue LED: operation indication

JUNG-F40-universal push-button module 4-gang-42941 ST

4-gang control panel-42941 ST replaces 4194 TSM, key frames and covers remain the same.

for cover kit 4-gang, ref.-no.: .. 404 TSA ..
for cover 4-gang with symbols, ref.-no.: .. 404 TSAP ..
can be extended by means of a push-button extension module, ref.-no.: 409.. TSEM
Adapter frames are included in delivery:
ref.-no. LS 4 AR for LS range (pre-mounted) and ref.-no. CD 4 AR for CD range.
AS / A ranges without adapter frame.
Only with ETS 5.7.7 or later versions or ETS6.0.6 or later versions the full functionality will be available.
ETS product family: Push-button
Product type: 4-gang push-button
1 blue LED: operation indication

KNX push button BCU - middle position -

Function: ON/OFF, roller shutters, variation
LED: always OFF/always ON/LED object, LED presentation
The LED is intended for orientation or status indication, adjustable through the
parameters.

Operating exemple :

• General OFF/ON control of the KNX lighting and one ON/OFF lighting
  or
• Control of 2 lights ON/OFF function
  or
• Control of 1 lights ON and OFF function
• Control of 2 lights ON/OFF/CLIMITER function
• Control of 1 roller shutter

The JUNG BP/BCU mechanisms are fitted with the finishing trims of the AS, A series, CD, SL and LS (SL series only button position).
Depending on the model of BP/BCU (1-way or 2-way) it is possible to use single or double button covers with or without indicator light.
Two white LEDs are intended to become orientation or status information depending on the selected parameters.
The "intermediate position" version can carry out a command by pressing the button up and down, whereas the "button position" version can only carry out a command by pressing the button down.
The BP/BCU operate with an application, i.e. they consist of a mechanism (hardware) and a program (software). With the aid of the application program it is possible to parameterize the functions and link group addresses (see JUNG database).

Please note that not all covers are compatible with this pushbutton. Here is a list of compatible covers in our catalogue:

- single cover

- single cover with indicator light

And in order to complete your knob, it is necessary to have a finishing frame. Below is the list of availability in our catalogue:

- 1-gang

- 2-gang

- 3-gang

- 4-gang

- 5-gang

KNX push button BCU - middle position -

Function: ON/OFF, roller shutters, variation
LED: always OFF/always ON/LED object, LED presentation
The LED is intended for orientation or status indication, adjustable through the
parameters.

Operating exemple :

• OFF/ON KNX General lighting control and a roller shutter
  or
• Control of 4 lights ON/OFF function
  or
• Control of 2 lights ON and OFF function
• Control of 2 lights ON/OFF/Dimmer function
• Control of 2 roller shutter

The JUNG BP/BCU mechanisms are fitted with the finishing trims of the AS, A series, CD, SL and LS (SL series only button position).
Depending on the model of BP/BCU (1-way or 2-way) it is possible to use single or double button covers with or without indicator light.
Two white LEDs are intended to become orientation or status information depending on the selected parameters.
The "intermediate position" version can carry out a command by pressing the button up and down, whereas the "button position" version can only carry out a command by pressing the button down.
The BP/BCU operate with an application, i.e. they consist of a mechanism (hardware) and a program (software). With the aid of the application program it is possible to parameterize the functions and link group addresses (see JUNG database).

Please note that not all covers are compatible with this pushbutton. Here is a list of compatible covers in our catalogue:

- dual cover

- dual cover with indicator light

And in order to complete your knob, it is necessary to have a finishing frame. Below is the list of availability in our catalogue:

- 1-gang

- 2-gang

- 3-gang

- 4-gang

- 5-gang

JUNG Glass Panel with 24 push-button sensor-IP54-KNX with status LED-MBT2424WW

Installation (IP54) in a double horizontal box (diameter 68mm), fixed by 4 screws.

Product characteristics:

- color: White

- Dimensions front plate: Width:236mm-Height:156mm-Depth:14mm

- Installation Depth: approx 39mm

- Push-button functions switching, dimming, controlling blinds, value transmitter,
calling up light scenes etc.
- High quality glass surface with 24 sensor buttons
- Operation via touching the sensor buttons
- Labelling with exchangeable labelling foil
- Status indication with 24 LEDs; the colours red, green and blue can be configured
- Acoustical feedback for touching sensor
- Fault message on dismantling
- Logic and time functions
- Integrated bus coupling unit
- Supply via separate power supply or the auxiliary voltage
output of the KNX power supply

JUNG Glass Panel with 24 push-button sensor-IP54-KNX with status LED-MBT2424SW

Installation (IP54) in a double horizontal box (diameter 68mm), fixed by 4 screws.

Product characteristics:

- Color: Black

- Dimensions front plate: Width:236mm-Height:156mm-Depth:14mm

- Installation Depth: approx 39mm

- Push-button functions switching, dimming, controlling blinds, value transmitter,
calling up light scenes etc.
- High quality glass surface with 24 sensor buttons
- Operation via touching the sensor buttons
- Labelling with exchangeable labelling foil
- Status indication with 24 LEDs; the colours red, green and blue can be configured
- Acoustical feedback for touching sensor
- Fault message on dismantling
- Logic and time functions
- Integrated bus coupling unit
- Supply via separate power supply or the auxiliary voltage
output of the KNX power supply
