Input module

Siemens KNX Pushbutton interface x4 4e/4s - UP 220D31 - 5WG1220-2DB31

Siemens KNX Pushbutton interface x4 4e/4s - UP 220D31 - 5WG1220-2DB31

With 4 inputs / outputs each configurable for potential-free contacts or for control of an LED (max 2 mA)
With integrated bus coupling unit, bus connection via bus terminal
8-wire plug-in cable set, 280 mm long, extendable to a max. of 10 m
For insertion in flush-mounting switch and socket boxes 60 mm in diameter and 40 mm deep

Functions for PL-Link

Functions for S-Mode KNX

79.50 €

Interra ITR106 :

Description :

ITR106 device is used to interface the contacts to KNX bus substructure such as push buttons, switches etc. to make them communicating devices.

Configuration and features :

The complete configuration of the device is performed via ETS3 or higher.
Depending on ETS configuration and settings the product feature will be different.
Avaialble functions are:
- Switching
- Dimming
- Toggle
- Blind Control
- 2 Channel
- Value Selected
Most of functions only need one input and therefore each input might be assigned a different function. However there are also some functions which use two inputs such as “Dimming with 2 buttons” and “Shutter/Blinds with 2 buttons”.

Mounting, commissionning and safety notes :

The device may only be installed and put into operation by a qualified electrician or authorized personnel.
The device is inserted in a flush-mounted combined joint box.
The installation location should not be in the outdoor area.
The voltage potentials on the lines connecting the contacts are not electrically isolated from the bus voltage.
Permitted cable length can be up to 5 meters and unused wires should be insulated.
Avoid contact with liquids and corrosive gases.
Do not get wrong connection for KNX Black and Red wires.
Please do not forget to recheck all connections after installation
