Zennio KES Plus KNX Electrical energy meter ZIO-KESP

 Up to 60A measurement per phase, requires the use of : Zennio 60A current transformer ref: ZN1AC-CST60

Up to 120A measurement per phase, requires the use of : Zennio 120A current transformer ref: ZN1AC-CST120

The nominal phase measurement current is 260A (see data sheet documentation), require the use of :

Zennio Current transformer 600A ref: 9900045

• Measurement of main electrical magnitudes.
• Suitable for 3-phase 4-wire or single-phase installations (3 lines).
• Power measurement (W or kW) and Energy with 3 registers.
• Currency and CO2 emissions estimation registers.
• KNX system clock synchronization is allowed.
• Up to 6 tariff cost-counters.
• Total data saving on KNX bus failure.
• Integrated KNX BCU.
• Dimensions 67 x 90 x 35mm (2 DIN units).
• DIN rail mounting (EN 50022), through pressure.
• Conformity with the CE directives (CE-mark on the right side).
